Hioki 3237 - Page 156

144
_____________________________________________________________________________________________
10.2 Accuracy
______________________________________________________________________________________________
Range
Maximum
display
Measurement
current
Open-circuit
voltage
Overload
protection
200 Ω 199.999 Ω 1mA 5%
6Vmax.
V
Ω
terminal:
500 Vpk
SENSE
terminal:
400 Vpk
2000 Ω 1999.99 Ω 1mA 5%
20 kΩ 19.9999 kΩ 100 uA 5%
200 kΩ 199.999 kΩ 10 uA 5%
2000 kΩ 1999.99 kΩ 1uA 5%
20 MΩ* 19.9999 MΩ 100 nA 5%
100 MΩ* 100.000 MΩ 20 nA 5%
Range SLOW MEDIUM FAST
Temperature
coefficient
200 Ω 0.03 , 8 0.03 , 18 0.03 , 300 0.003 , 0.8
2000 Ω 0.02 , 2 0.02 , 12 0.02 , 100 0.002 , 0.2
20 kΩ 0.02 , 2 0.02 , 12 0.02 , 100 0.002 , 0.2
200 kΩ 0.02 , 2 0.02 , 12 0.02 , 100 0.002 , 0.2
2000 kΩ 0.03 , 2 0.03 , 12 0.03 , 200 0.003 , 0.2
20 MΩ*
1
0.2 , 4 0.2 , 20 0.2 , 200 0.02 , 0.4
100 MΩ*
1
3,10 3,50 3 , 500 0.3 , 1
Range
Maximum
display
Measurement
current
Open-circuit
voltage
Overload
protection
2000 Ω 1999.99 Ω 100 uA 5%
0.45 Vmax. 500 Vpk
20 kΩ 19.9999 kΩ 10 uA 5%
200 kΩ 199.999 kΩ 1uA 5%
2000 kΩ 1999.99 kΩ 100 nA 5%
Range SLOW MEDIUM FAST
Temperature
coefficient
2000 Ω 0.02 , 6 0.02 , 14 0.02 , 300 0.002 , 0.6
20 kΩ 0.02 , 6 0.02 , 14 0.02 , 300 0.002 , 0.6
200 kΩ 0.02 , 6 0.02 , 14 0.02 , 300 0.002 , 0.6
2000 kΩ 0.2 , 6 0.2 , 20 0.2 , 300 0.02 , 0.6
Resistance Measurement Function (2-/4- terminal)
(1) Range
*: 2-terminal resistance measurement
(2) Accuracy % rdg. dgt. (After performing zero ajust)
(*1): 2-terminal resistance measurement
*: Contact resistance: 100 Ω or less (4-terminal resistance measurement)
Low-power Resistance Function (2-/4- terminal)
(1) Range
(2) Accuracy % rdg. dgt. (After performing zero ajust)
*: Contact resistance: 100 Ω or less (4-terminal resistance measurement)
