Hioki 3237 - Page 59

47
_____________________________________________________________________________________________
6.2 Timing Chart
______________________________________________________________________________________________
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Contents
Time
MIN TYP MAX
T1 Measurement trigger ( TRIG
―――――――
)
pulse width
500 μ s
－ －
T2 Trigger delay time Refer to 4.5.3 Trigger Delay
T3 Measuring time* FAST
－
3.3 ms
－
MEDIUM 130 ms (50 Hz) / 108 ms (60 Hz)
SLOW 1.04 s (50 Hz) / 1.08 s (60 Hz)
T4 Computing time
－
2ms
－
T5 From EOC=Lo until input of trigger
( TRIG
―――――――
)
500 μ s
－ －
T6
EOC
―――――――
Measurement end
signal
Hi
―――
,IN
―――
,Lo
―――
Comparator result output
Contents
Time
MIN TYP MAX
T6 Measurement end
signal (EOC
―――
)
pulse width
FAST
－
1.7 ms
－
MEDIUM
－
50 ms
－
SLOW
－
500 ms
－
*: Reference value. With the Average function, the measuring time is
determined by multiplying the measuring time by the number of averaged
measurements.
This varies with the function range. Use the sampling period (free run) in
Chapter 10 Specification as a guide.
When set to FAST, the unit performs a self-calibration every 30 minutes
for a duration of approximately 55 ms each time.
(2) Internal trigger mode
