8.1 General Specifications
索引
4
3
2
1
7
6
5
10
9
8
Specifications
Zero-adjustment
Details of
operation
Measured values upon implementation
(upon obtaining adjusted values) are set at
zero
Initial status OFF
Adjustment
range
Up to 300 counts for each range
(resistance, voltage)
Auto holding of measured values
Details of
operation
Holding (ceasing updating of) displayed val-
ues
Hold method (1) Pressing the
HOLD key
(2) Inputting signals to the EXT.HOLD/
MEMO terminal
(3) Stabilizing measured values
(when the auto-hold feature is on)
Comparator feature
Details of
operation
Comparison of measured values with permissi-
ble values
Initial status OFF
Setting
method
Press the COMP key to select the comparator
no. to use
Configure resistance upper limit no. 1, resistance
upper limit no. 2, and the voltage lower limit.
Settings saved 200
Resistance
(low)
Resistance
(medium)
Resistance
(high)
Voltage (high) PASS WARN FAIL
Voltage (low) WARN WARN FAIL
