Hioki 3554 - Setting the Comparator Buzzer

61
4.4 Setting the Comparator Buzzer
索引
4
3
2
1
7
6
5
10
9
8
Comparator Feature
When using the comparator feature, the buzzer can be set to
sound in accordance with judgment results. The following condi-
tions can be set. The initial configuration is "warn/fail (on)."
When you press key, the current comparator buzzer set-
tings will be displayed. Keep the button pressed to switch
between settings.
After approximately one second passes with no settings made,
the settings displayed will be entered and the instrument will
return to the measurement screen.
4.4 Setting the Comparator Buzzer
OFF No buzzer sounds regardless of the results of
judgment.
PASS (ON) The buzzer sounds when the results of judg-
ment are "pass."
WARN/FAIL
(ON)
The buzzer sounds when the results of judg-
ment are "warning" or "fail."
The sound emitted when pressing the keys cannot
be changed.
WARN / FAIL
OFF
PASS
