10.6 Test Lead Options
154
10.6.3 Model 9467 LARGE CLIP TYPE LEAD
These can be clipped to samples in relatively thick bar form.
Four-terminal measurement can be conducted just by clipping
these to the subject.
Distance between the split and the probe:
approximately 250 mm
Distance between the connector and the split:
approximately 850 mm
Maximum clip diameter: approximately 29 mm
10.6.4 Model 9772 PIN TYPE LEAD
This lead's pins are arranged parallel to each other. It is a strong,
wear-resistant lead.
Probe (red)
Probe (black)
SOURCE
SENSE
Banana plug (black)
Banana plug (red
)
+
-
9.15
4.3
2.5
φ1.8
(Unit: mm)
