3.4.3 Holding Using the EXT.HOLD/MEMO Ter-
minal
The EXT.HOLD/MEMO terminal can be used for the same pur-
poses as key. This requires the optional 9466 REMOTE
CONTROL SWITCH.
1. Disconnect the test lead from the battery subject to
measurement.
2. Insert the miniplug of the 9466 REMOTE CON-
TROL SWITCH into the EXT.HOLD/MEMO termi-
nal.
3. Press the PRESS button on the 9466 to hold the
measurement values.
4. To cancel the hold, press the PRESS button on the
9466 switch or press key on the instrument.
• Holding cannot be conducted when the following
values are displayed: "- - - -"
• Be sure not to insert or remove the miniplug
while the test lead is connected to the battery
subject to measurement. Connect the handy
switch only after disconnecting the test lead from
the battery.
• Do not insert the miniplug of the 9466 REMOTE
CONTROL SWITCH into the TEMP.SENSOR
terminal.
