7.2 Installing the Software
84
Before connecting the instrument to a personal computer, be
sure to install Application Software for 3554.
7.2.1 Installation
7.2 Installing the Software
1.
Start up the personal computer.
2.
Stop all applications being executed on the computer
(recommended).
3.
Insert the CD that came with the instrument (Application
Software for 3554) into the computer's CD-ROM drive.
4.
Select the language to use.
Application Software for
3554
Once the computer has detected the
CD-R, the [install] screen will be dis-
played on the computer's screen.
Click
* If the [install] dialog is not di
s-
played automatically, execut
e
the installation program from
the following location: X:\En
-
glish\Application3554v1.00E
_
setup.exe (for Ver. 1.00).
("X" in the above file location
indicates the CD-ROM drive
.
The letter allocated to the CD
-
ROM drive may vary by com
-
puter.)
