3.2 Setting the Measurement Range
36
Set resistance and voltage measurement ranges as described
below.
Press key to display the current settings. Press the key
repeatedly to select the desired range.
After approximately one second passes with no settings made, the settings
displayed will be entered and the instrument will return to the measure-
ment screen.
Press key to display the current settings. Press the key
repeatedly to select the desired range.
After approximately one second passes with no settings made, the settings
displayed will be entered and the instrument will return to the measure-
ment screen.
3.2 Setting the Measurement Range
Resistance Range 3 mΩ / 30 mΩ / 300 mΩ / 3 Ω
Voltage Range 6 V / 60 V
Temperature Range (Single range) Since temperature measurement
uses a signal range, range setting is unnecessary.
Resistance Measurement Range
Voltage Measurement Range
3.000 mΩ
30.00 mΩ
300.0 mΩ
3.000 Ω
6.000 V
60.00 V
