Helicopte
r
PTCV
-
Pitch
Curve
Like
the
throttle
curve
described
previously,
pitch
curves
are
tied
to
the
position
of
the
throttle
collective
stick,
and
are
specified
at
five
points
labeled
1
through
5
below.
Setup
instructions
are
the
same
as
those
for
throttle
curve,
except
that
you
may
also
input
a
curve
for
the
throttle
hold/
ST3
flight
mode.You
can
get
a
linear
response
by
making
the
five
settings
line
up
as
shown
above.
But
if
you
want
another
shape,
you're
free
to
do
it.
You
can
"flatten
out"
or
"soften"
the
curve
around
hover,
which
is
handy
for
making
the
control
less
sensitive
there.
Inputting
The
Pitch
Curve
Values
1.
Press
one
of
the
Up
Down
Edit
buttons
until
the
PTCV
window
appears.
The
default
is
for
a
linear
curve,
a
straight
line
from
0
to
100%
passing
through
50%
at
hover
(center).
2.
Be
sure
you're
in
the
desired
flight
Modes
by
moving
the
Flt.
Mode
switch
(
SW-4)
to
its
proper
position.
Remember,
you
can
input
separate,
independent
throttle
curve
settings
for
each
separate
idle-up
mode.
3.
You
begin
at
set
point
#
1
,
idle.
A
small
arrow
should
appear
over
the
number
1
in
the
display,
and
a
value
of
0%
should
be
shown.
Press
the
Data
+Increase
or
-
Decrease
key
to
change
the
setting
to
your
desired
value.
4.
When
you're
finished
with
Point
1,
move
to
the
next
point
with
the
Cursor
Right
key.
A
small
arrow
over
the
number
2
indicates
you
are
setting
the
value
for
Point
2.
Note
that
the
function
is
inhibited
(
Inh
)
to
start
with.
If
you
leave
it,
you
get
a
straight
line
from
points
1
to
3.
Otherwise,
you
can
change
this
setting
with
the
Data
+Increase
or
-
Decrease
keys.
5.
Repeat
this
procedure
for
Points
3,
4,
and
5
by
pressing
the
Cursor
Right
key,
then
adjusting
as
desired
with
the
Data
+Increase
or
-Decrease
keys.
6.
When
you've
completed
the
settings
for
the
first
flight
mode
(
NOR
),
test
fly
your
model.
When
you're
satisfied
with
the
settings,
use
them
as
a
basis
for
the
other
flight
Modes.
Flip
the
switches
as
necessary
to
get
into
the
new
mode,
verify
on
the
display
that
you
are
in
the
desired
flight
mode,
then
set
all
the
five
points
in
by
going
through
the
steps
given
previously.
S/W SEL
-
Switch
Selection
For
Auxiliary
Functions
Your
Optic
system
allows
you
customize
your
radio
and
choose
what
switches
are
used
to
turn
on
the
following
helicopter
functions:
AIL
D/R,
ELEV
D/R,
RUDD
D/R,
R->T,
HOLD,
PMX1,
and
PMX2
.
Note
that
each
of
these
functions
may
be
chosen
to
be
turned
on
by
flipping
a
switch.
Some
may
be
selected
to
be
on
all
the
time.
Choosing
The
On-Off
Switch
For
Certain
Radio
Functions
1.
Call
up
the
S
witch
Select
screen
by
repeatedly
pressing
one
of
the
Edit
Up
Down
keys
until
the
highlighted
words
S/W
SEL
appear.
The
window
may
appear
with
any
of
the
following
displayed:
AIL
D/R,
ELEV
D/R,
RUDD
D/R,
R->T,
HOLD,
PMX1,
and
PMX2
.
Note
that
if
you
change
switch
locations,
the
switch
labeled
(for
example)
AIL
D/R
or
SW-4
will
not
control
aileron
dual
rate
afterwards.
You
should
carefully
consider
how
you
assign
all
the
switches
in
consideration
of
the
flight
mode
switches.
S
ee
also
Item
3a
below.
2.
Use
the
Data
+Increase
or
-Decrease
keys
to
select
the
desired
function.
3.
Use
the
Left
Right
Cursor
keys
to
select
from
the
following
on-off
possibilities
for
the
selected
function
a.
On
indicates
the
function
is
ALWAYS
on.
You
can
also,
for
example,
set
HOLD
to
be
On
at
all
times.
This
will
permanently
disable
the
throttle
servo,
not
a
good
thing!
Be
very
careful
choosing
ON
as
a
possible
setting
for
all
of
these
functions.
b.
1
represents
Switch
SW-1
,
the
"ELEV
RUDD
D/R"
switch.
On
is
down
.
c.
2
represents
Switch
SW-2
,
the
"GEAR
AUX"
switch.
On
is
down
.
d.
3
represents
Switch
SW-3
,
the
"AIL
D/R"
switch.
On
is
down
.
e
.
4
represents
Switch
SW-4
,
the
"FLT
MODE"
switch.
The
FLT
MODE
switch
has
three
positions
to
select
from:
i.
NOR
=onat
forward
position
ii.
ST1
=onat
middle
position
iii.
ST2
=onat
aft
position
4.
Repeat
Steps
2-3
for
any
additional
functions
you
wish
to
set
Men
u
Description
s
-
Helicopter
-
Pa
g
e
5
3
