12
Vehicle Care 10-5
Engine Compartment Overview
V6 Engine
A
B C D
E
F
(SIDI) direct injection V6 engine shown
A. Engine coolant reservoir, see
Engine Coolant on page 10‑ 9
B. Brake fluid reservoir, see Brake
Fluid on page 10‑ 16
C. Engine oil filler cap, see Engine
Oil on page 10‑ 8
D. Dipstick for engine oil, see
Engine Oil on page 10‑8
E. Power steering fluid reservoir,
see Power Steering Fluid on
page 10‑14
For access to the cap, see
Engine Cover on page 10‑ 6
F. Windscreen washer fluid
reservo ir, see Washer Fluid on
page 10‑15
