Black plate (26,1)
Holden WM Caprice Owner Manual (MY12.5) - 2012 - CRC 1st Edition - 6/28
12
10-26 Vehicle Care
A. Locking tang
B. Rear number plate
1. Push the locking tang (A)
towards the lens.
2. Pull the lamp assembly
downwards.
3. Remove the bulb holder from the
light housing by rotating the bulb
holder anticlockwise.
4. Pull the bulb out of the bulb
holder.
5. Push the new bulb into the bulb
holder.
6. Install the bulb holder into the
light housing by rotating the bulb
holder clockwise, ensuring that
the seal is undamaged.
7. Install the light assembly into the
surround.
8. Check light operation.
Interior Lights
Rear dome/reading lights
(W5W bulb)
The vehicle has rear interior dome/
reading lights:
1. Pull the forward edge of the
dome light downwards, using
fingers only.
2. From the rear side, remove the
bulb holder from the light
housing by rotating the bulb
holder anticlockwise.
Note: Do not remove the lens from
the light assembly.
3. Pull the bulb out of the bulb
holder.
4. Push the new bulb into the bulb
holder.
5. Install the bulb holder into the
light housing by rotating the bulb
holder clockwise.
6. Refit the light into the r earward
facing locating tabs.
7. Push the forward facing edge
upward into the head li ning until
firmly in place.
8. Check light operation.
Rear dome/reading lights with
Rear Seat Entertainment (RSE)
(W5W bulb)
