Black plate (27,1)
Holden WM Caprice Owner Manual (MY12.5) - 2012 - CRC 1st Edition - 6/28
12
Vehicle Care 10-27
The vehicle may have RSE.
1. Pull down on the left or right
edge of the light section using
only fingers.
2. From the rear, remove t he bulb
holder from the light housing by
rotating the bulb holder
anticlockwise.
3. Pull the bulb out of the bulb
holder.
4. Push the new bulb into the bulb
holder.
5. Install the bulb holder into the
light housing by rotating the bulb
holder clockwise.
6. Refit the light section by firmly
pushing it directly upward into
the console.
7. Check light operation.
Glove box light, door courtesy
lights
(Festoon bulb, 5W)
1. Remove the lens housing with a
fine flat-blade screwdriver.
2. Pull the tab holding the bulb
(opposite end to wiring)
backwards and pull the bulb out.
3. To install a new bulb, pull the tab
backwards.
4. When the new bulb is in place,
feed the wiring back into the
cavity and push the lens housing
back into place.
