Honeywell 301C User Manual

510324 301C User Manual ix
4/07 Honeywell
Contents
INTRODUCTION ............................................................13
Intended Use ......................................................................................... 13
Receiving and Unpacking ...................................................................... 13
Installation Instructions ...................................................................... 14
Basic Guidelines .................................................................................... 14
Surface Mount Installation ..................................................................... 15
Wiring Details .................................................................................... 16
Power Connections ........................................................................... 18
Communication Connections ............................................................ 18
Relay Output ..................................................................................... 19
Jumper Use Instructions ........................................................................ 20
GETTING STARTED ......................................................21
Initial Startup ......................................................................................... 21
Datalogger (SDcard) ............................................................................. 21
Programming Interface ......................................................................22
Keypad Functions .................................................................................. 22
LED Definitions ...................................................................................... 23
System Operation .................................................................................. 23

Honeywell 301C Specifications

General

Controller Type	Temperature Controller
Control Mode	ON/OFF, PID
Input Voltage	100-240 VAC
Input	Thermocouple, RTD
Output	Relay, SSR
Operating Temperature	0 to 50°C
Contact Rating	5A @ 250 VAC (Relay)
