70 301C User Manual 510324
Honeywell 4/07
System Programming
Tests Menu
Test Sequence
When you select test sequence from the main Tests menu, the
controller will display the Test sequence screen.
If you press Esc on the keypad, you will return to the main Tests menu
screen. However, if you wish to perform system tests, press any key to
proceed to the first test screen.
This screen will test each component individually and will only advance
to the next component when you press a key. This option will display
13 separate screens in all. Screens 1, 2 and 3 test Relays, BUZZER
and LEDs.
The following six screens prompt you to press the keypad buttons, in
turn: left, right, up, down, Silence, Enter and Esc. The system will not
advance unless you press the key.
Test sequence
Relays activated
Any key to continue
Esc to quit
Test sequence
BUZZER activated
Any key to continue
Esc to quit
Test sequence
Press ‘left’
Esc to quit
