BACnet/IP MODULE
Honeywell Products and BACnet Objects
Object Names
Object names are constructed in two parts, as follows:
Part one: The device display label (product name) for the network in
which the object resides. This value is editable only when
using the 301C controller.
Part two: Unique tag label among all the objects for the same device.
Ex : “301D2 CO2 AD:14.CO2” where ‘301D2 CO2 AD:14’ is the
device display label and ‘CO2’ is the unique tag label that identifies the
object as a CO2 sensor.
Vulcain Object Tag Labels
Table 1:
Tag Labels Description
Object
Type
‘Gas label’ Gas sensor AI
.Alrm Simple alarm level AV
Amin /Amax Alarm level A and hysteresis AV
Bmin /Bmax Alarm level B and hysteresis AV
Cmin /Cmax Alarm level C and hysteresis AV
relx Relay output X (1 to 8) BO
buzz Buzzer output BO
.outx Output X (1 to 3) BO or BV
.AIx Analog input X (1 to 16) AI
.BIx Binary Input X (1 to 12) BI
.RH Relative Humidity sensor AI
.Temp Temperature sensor AI

Honeywell 301C Specifications

General

Controller Type	Temperature Controller
Control Mode	ON/OFF, PID
Input Voltage	100-240 VAC
Input	Thermocouple, RTD
Output	Relay, SSR
Operating Temperature	0 to 50°C
Contact Rating	5A @ 250 VAC (Relay)
