4. OPERATION
4-20mA Set Zero
ok
4-20mA Set Zero screen
Set zero value -
3.5mA to 4.5mA
ok
Use up/down
buttons
Calibration Menu
4-20mA Set Zero Calibration Menu
This option allows the This option allows
thezeropointwithinthe4-20mAsignal
range to be adjusted between 3.5
and4.5mA.Thedefaultsettingis4.0mA.
Theoffsetappliestoall4-20mAoutput
states including Inhibit, Warning, Overrange
and Alarms.
Force 4-20mA Calibration Menu
Caution: Ensure that when forcing a signal on the 4-20mA output that the effects on the
network and controller are understood.
Thisoptionallowsthe4-20mAoutputto
beforcedtoalevelselectedbetween0
and 22mA. The default is 1mA. The forced
setting times out after approximately
5 minutes and the output returns to
normal active operation.
Force 4-20mA
ok
Force 4-20mA screen
Set value - 0mA
to 22mA
esc
Use up/down
buttons
Calibration Menu

Honeywell Apex Specifications

General

Type	Addressable Fire Alarm Control Panel
Power Supply	120/240 VAC, 50/60 Hz
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	10% to 93% non-condensing
Compatibility	Honeywell Notifier devices and compatible peripherals
Certifications	UL, FM, CSFM
