Second Screen
The second screen is displayed after navigating past the last entry on the initial screen by using the
down button.Atypicalexampleisasfollows:
Current Config
FaultRelay: NE/L
Alarm1 Relay:
Tx Version: 1.02
Sensor
NE/NL
Alarm2 Relay: NE/NL
Version: 1.2
Fault Relay  Reportsthecontactconguration(seeNote)fortheFaultRelay.
Alarm1 Relay  Displaysthecontactconguration(seeNote)fortheAlarm1Relay.
Alarm2 Relay  Reportsthecontactconguration(seeNote)fortheAlarm2Relay.
Tx Version Displays the current version of the transmitter software.
Sensor Version ReportsthecurrentversionoftheCertiedSensorsoftware.
Note:
The abbreviations used on the screen for the contact settings mean
the following:
ND Normally De-energised
NE Normally Energised
L Latching
NL Non-Latching
4.4.4 History Log Menu
The History Log Menu enables the recorded log for the unit to be viewed by the operator and
also reset, or cleared. The logcontains information about events that happen during the life of the
TransmitterUnit,e.g.timeoflastCertiedSensorcalibration,timeoflastalarm,etc.
This menu is protected by a Level 2 password.
4. OPERATION
History Log Menu
View History Log
Reset History Log
