Parameter Modifications
at Run-time
CAUTION
Do not modify Parameters P5 to P18 during power calculations. Improper
power calculations may result.
Using the Sliding Window algorithm, parameter modifications are introduced into the
calculations when a sample occurs (every tenth of Parameter P10). Using the other
two algorithms, Ideal Curve and Extrapolation, the parameter modifications are
introduced into the calculation at the beginning of a measurement interval (after
receiving a synchronization pulse).
After one or more parameters (P5 to P18) have been modified, Parameter P8
must be set to 1. This tells the calculation algorithm that parameters have been
modified to include them in a coordinated manner. When the time arrives to include
the modifications, the calculation algorithm writes the value 2 to Parameter P8,
registers the modifications and resets P8 to 0 to show that the modified parameter
values are now in use.
Parameter P8 can be used as a Test Board parameter by setting it to 3. In this
operating mode, the maximum switch-on power value P5 is transmitted to the loads
every calculation interval (sample) until all loads are switched on. To return to the
normal operating mode, the user must reset the Parameter P8 to 0.
The following table lists the parameters used for the parameter modification at run-
time function.
Parameter
Number Type Brief Description
Setting
Range
Default
Value Unit
5 Comm. Maximum Switch-on Power 1-1000 10 kW
6 Comm. Safety Margin 0-1000 0 kW
7 Comm. Hysteresis for Power Switching 0-1000 0.5 kW
8 Comm. Test Board / Parameter Change (set to 1 when
changing any other parameters)
0/1/2/3 2 Integer
9 Comm. Measurement Algorithm
1=Sliding Window
2=Ideal Curve
3=Extrapolation
1/2/3 3 Integer
10 Comm. Measurement Interval/Window Size 1-7200 15 min
11 Comm. Freeze Time 30-300 180 sec
12 Comm. Switch-on Wait Time 0-240 120 sec
13 Comm. Power Limit 1
0-10
6 10000 kW
14 Comm. Power Limit 2
0-10
6 10000 kW
15 Progr. Sequential / Rotating (0 / 1) Priority 1 0/1 0 Integer
16 Progr. Sequential / Rotating (0 / 1) Priority 2 0/1 0 Integer
17 Progr. Sequential / Rotating (0 / 1) Priority 3 0/1 0 Integer
18 Progr. Offset Factor "a" (just for Ideal Curve Algorithm) 0-1000 0 Integer
