1. Power to switch Po VA Power switching value to next XFM 36-1
or to XFM 35
2. Load stage St DO (1/6 XF
524)
Load switching command (ON/OFF).
Output to a relay or other modules (for
example, a switching table).
Type abbreviations:
DI: Digital input
VA: Virtual (pseudo) analog
DO: Digital output
Datapoints Button Click this button to display the Datapoints dialog box for XFM 36-1, 36-1S or 36-1R.
Click on Set for each XFM Pointname. CARE automatically creates user addresses
with the same names. Edit the user names that require a priority group member (1,
2, or 3.). Later sections describe how to use these points depending on operation
desired. The table following the dialog box summarizes user address types and
functions.
Datapoints from
XFM 36 I/O Dialog Box
