1 Display Rotational/Sequential (Operating Mode)
1=rotational; 0=sequential
36-1:
none
36-1S
36-1R
none
0
1
lnteger
2 Display Po_Power_to_Switch (switching power input) none none kW
3 Display RM_Input_Feedback (see RM Functions
section)
none none lnteger
4 Display “St”_Output_Stage (current load status)
1=on; 0=off
none none lnteger
5 Display Minimum_On_active (ON time active=1) none none lnteger
6 Display Minimum_Off_active (OFF time active=1) none none lnteger
7 Display Maximum_Off_expire (OFF time expired=1) none none lnteger
8 Display Switch_On_Index (equals IA___On_Index
P1/2/3) in sequential mode; longest on time in
rotational mode)
none none lnteger
9 Display Switch_Off_Index (no function in sequential
mode; load off time in rotational mode) XFM
36-1 and 36-1R
none none lnteger
Int Internal Parameter (XFM 36-1S) 0 0 ---
10 Comm. Minimum_On_time 0-300 60 sec
11 Comm. Minimum_Off_time 0-400 60 sec
12 Comm. Maximum_Off_time
0=No max off-time function
0-1440 15 min
13 Comm. Mode_of_Operation
0=Auto; 1=ON; 2=OFF
0/1/2 0 lnteger
14 Progr. Load_Number (priority rank within a group)
0=RM for status feedback
1=RM and Po
2=No RM function
1-50 1 lnteger
15 Progr. Power_of_the_Load (highest number is shed
first)
0-1000 1000 kW
16 Progr. Feedback_Op_Mode
0=RM for status feedback
1=RM and Po
2=No RM function
0/1/2 2 lnteger
17 Int. Internal_Parameter 0 0 lnteger
18 Int. Internal_Parameter 0 0 lnteger
19 Int Version fix fix lnteger
20 Int XFM_Number fix 36.1 (XFM 36-1)
36.11 (XFM 36-1S)
36.12 (XFM 36-1R)
lnteger
Type abbreviations:
Display indicates the program´s internal calculated values.
Comm. is used by a commissioning engineer to set or adjust specific plant values.
Progr. can be preset by the programming engineer (using CARE) and revised by the
commissioning engineer.
Int is an internal parameter that you must not modify.
