30 Series Network Video Recorder User Guide
72
Record: to manually record for a single camera
5. Select the Clips tab and select a channel.
6. To search the clips:
a) Enter the Start Date and the End Date.
b) Select the event types which can be Motion, Schedule, Trigger, User Driven, or Rule
Driven.
c) Select the storage option, which can be On Cloud (clips on MPC), On Site (clips on
the device), or Both.
d) Click Apply.
7. Drag and drop to view a recorded clip. Up to six clips can playback simultaneously.
Upgrade Firmware
MPC allows the user to upgrade the firmware of 30 Series NVR.
To upgrade the firmware
1. Click and select Firmware.
2. Select the Sites and the Controller Type and click Search.
Figure 6-62 Search Firmware
3. Select the check-box under Site or Customer.
4. Select the firmware version for update from the Available Version.
5. Click Update.
Check Alarms
Alarms notify the occurrence of alarms and events selected during setup that occur in any of
the connected systems to the operators. Alarms require further action by the operator. Some
of the typical alarms are: Input, Motion, Hard disk error, Video Loss, Video OK, Video
Disconnect, Camera Disconnect.
Alarms with no severity are events. Every event and alarm is sent as a notification.
To view the Alarms page
