Configuring via the Web Server
Configuring the Doors
CID B Lists where on the card the Card ID B is listed.
Start Bit – first bit in the card where card ID begins.
Num Bits – Number of bits to the right of the start bit,
including the start bit, that comprise the card ID.
Most formats require only CID A, and not CID B, C, or D.
Card ID C Lists where on the card the Card ID C is listed.
Start Bit – first bit in the card where card ID begins.
Num Bits – Number of bits to the right of the start bit,
including the start bit, that comprise the card ID.
Most formats require only CID A, and not CID B, C, or D.
Card ID D Lists where on the card the Card ID D is listed.
Start Bit – first bit in the card where card ID begins.
Num Bits – Number of bits to the right of the start bit,
including the start bit, that comprise the card ID.
Most formats require only CID A, and not CID B, C, or D.
Site Code A Lists where on the card the Site Code A is listed. Consult
the card manufacturer for detail on the card detail.
Start Bit – first bit in the card where the card’s Site Code
begins.
Num Bits – Number of bits to the right of the start bit,
including the start bit, that comprise the Site Code.
Most card formats require only Site Code A.
Site Code B Lists where on the card the Site Code A is listed. Consult
the card manufacturer for detail on the card detail.
Start Bit – first bit in the card where the card’s Site Code
begins.
Num Bits – Number of bits to the right of the start bit,
including the start bit, that comprise the Site Code.
Most card formats require only Site Code A.
Site Code C Lists where on the card the Site Code A is listed. Consult
the card manufacturer for detail on the card detail.
Start Bit – first bit in the card where the card’s Site Code
begins.
Num Bits – Number of bits to the right of the start bit,
including the start bit, that comprise the Site Code.
Most card formats require only Site Code A.
Table 2-5: Configuration > Doors > Reader > Card Format Fields (continued)
Setting Description
