HP 5120 EI Series User Manual

190
T
yp
e Descri
p
tion
Protocol Identity
Indicates protocols supported on the port. An LLDPDU can carry multiple
different TLVs of this type.
NOTE:
HP devices support only receiving protocol identity TLVs.
3. IEEE 802.3 organizationally specific TLVs
Table 25 IEEE 802.3 organizationally specific TLVs
T
yp
e Descri
p
tion
MAC/PHY
Configuration/Status
Contains the bit-rate and duplex capabilities of the sending port, support for
auto negotiation, enabling status of auto negotiation, and the current rate
and duplex mode.
Power Via MDI
Contains the power supply capability of the port, including the Power over
Ethernet (PoE) type, which can be Power Sourcing Equipment (PSE) or
Powered Device (PD), PoE mode, whether PSE power supply is supported,
whether PSE power supply is enabled, and whether the PoE mode is
controllable.
Link Aggregation
Indicates the aggregation capability of the port (whether the link is capable
of being aggregated), and the aggregation status (whether the link is in an
aggregation).
Maximum Frame Size
Indicates the supported maximum frame size. It is now the maximum
transmission unit (MTU) of the port.
Power Stateful Control
Indicates the power state control configured on the sending port, including
the power type of the PSE or PD, PoE sourcing and receiving priority, and
PoE sourcing and receiving power.
NOTE:
The Power Stateful Control TLV is defined in IEEE P802.3at D1.0. The later versions no lon
g
er support this
TLV. HP devices send this type of TLVs only after receiving them.
LLDP-MED TLVs
LLDP-MED TLVs provide multiple advanced applications for voice over IP (VoIP), such as basic
configuration, network policy configuration, and address and directory management. LLDP-MED TLVs
provide a cost-effective and easy-to-use solution for deploying voice devices in Ethernet. LLDP-MED TLVs
are shown in Table 26.
Table 26 LLDP-MED TLVs
T
yp
e Descri
p
tion
LLDP-MED Capabilities
Allows a network device to advertise the LLDP-MED TLVs that it
supports.
Network Policy
Allows a network device or terminal device to advertise the VLAN ID of
the specific port, the VLAN type, and the Layer 2 and Layer 3 priorities
for specific applications.
Extended Power-via-MDI
Allows a network device or terminal device to advertise power supply
capability. This TLV is an extension of the Power Via MDI TLV.
