Hardware options installation 113
DIMM specifications
DIMM specifications – Intel Xeon E5-2600 v3 processor installed
Type
Rank
Capacity (GB)
Native speed (MT/s)
Voltage
RDIMM
Single
4
2133
STD
RDIMM
Single
8
2133
STD
RDIMM
Dual
8
2133
STD
RDIMM
Dual
16
2133
STD
RDIMM
Dual
32
2133
STD
LRDIMM
Dual
16
2133
STD
LRDIMM
Quad
32
2133
STD
DIMM specifications – Intel Xeon E5-2600 v4 processor installed
Type
Rank
Capacity (GB)
Native speed (MT/s)
Voltage
RDIMM
Single
8
2400
STD
RDIMM
Single
16
2400
STD
RDIMM
Dual
16
2400
STD
RDIMM
Dual
32
2400
STD
LRDIMM
Dual
32
2400
STD
LRDIMM
Dual
64
2400
STD
Populated DIMM speed (MT/s)
Operating memory speed is a function of rated DIMM speed, the number of DIMMs installed per channel,
processor model, and the speed selected in the BIOS/Platform Configuration (RBSU) of the UEFI System
Utilities ("HPE UEFI System Utilities" on page 159).
Populated DIMM speed – Intel Xeon E5-2600 v3 processor installed
Type
Rank
1 DIMM per channel (MT/s)
RDIMM
Single
2133
RDIMM
Dual
2133
LRDIMM
Dual
2133
LRDIMM
Quad
2133
Populated DIMM speed – Intel Xeon E5-2600 v4 processor installed
Type
Rank
1 DIMM per channel (MT/s)
RDIMM
Single
2400
RDIMM
Dual
2400
LRDIMM
Dual
2400
Maximum memory capacity
Maximum memory capacity is a function of DIMM capacity, number of installed DIMMs, memory type, and
number of installed processors.
Maximum memory capacity – Intel Xeon E5-2600 v3 processor installed
DIMM type DIMM rank
Capacity
(GB)
Maximum capacity for
one processor (GB)
Maximum capacity for
two processors (GB)
RDIMM
Single-rank
4
32
64
RDIMM
Single-rank
8
64
128
