Operations 34
Close the cable management holder
1. Return the cable management holder to its original position.
2. Secure all disconnected system cables in the cable management holder, and then connect them to
the system board and/or controller board.
3. Pull and hold the drive cage rail release latches, and then slide the drive cages back into the chassis.
4. Install the air baffle (on page 32).
Remove the PCI riser cage
WARNING: To reduce the risk of personal injury from hot
surfaces, allow the internal system
components to cool before touching them.
CAUTION: To prevent damage to electrical components, take the appropriate anti-static
precautions before beginning any installation, removal, or replacement procedure. Improper
grounding can cause electrostatic discharge.
