2. Slowly pull the server forward by the handles until it is fully extended.
NOTE: The server is fully extended when the rail clips are locked in place and the top
cover is completely accessible.
Figure 6-1 Extending the Server from the Rack
Inserting the Server into the Rack
To insert the server into the rack, follow these steps:
1. Press the rail clips on both sides of the server inward.
2. Push the server into the rack until it stops.
Accessing a Pedestal Mounted Server
The server is also designed for use in a pedestal-mount configuration. The pedestal mount kit
is a sheet metal enclosure that positions the server vertically. See the HP Integrity rx2660 Server
Pedestal Installation Guide pedestal mounting kit documentation for the installation and access
procedures.
Removing and Replacing the Top Cover
NOTE: When the top cover is open or removed while the server is running, the server fans
increase to high speed to assist cooling. When the top cover is replaced at the end of the operation,
the server fans return to normal speed. The top cover must be replaced onto the server within
three minutes, or the server shuts down automatically.
Removing the Top Cover
To remove the top cover, follow these steps:
1. If rack mounted, fully extend the server out from the rack. See “Extending the Server from
the Rack” (page 142).
2. Using the Allen wrench, provided on the rear panel of the server, unlock the cover release
lever (if necessary) by turning the cam approximately 90 degrees counter-clockwise (1).
3. Pull up on the cover release lever to disengage the top cover from the server (2).
4. Slide the cover toward the rear of the server until the tabs release from the slots in the chassis
(3).
5. Lift the cover off the server (4).
Accessing a Pedestal Mounted Server 143
