Figure 6-29 Processor Cage Open
Figure 6-30 shows the power connector and cable for the processor.
Figure 6-30 Processor Power Connectors and Cables
Figure 6-31 shows the processor ZIF socket location and the alignment holes of an installed
processor.
321
ProcessorPower cable from the
system board
Power connector on the
processor
178 Removing and Replacing Server Components
