Figure 6-8 Office Friendly Server Cooling Zones
Removing a Server Fan
CAUTION: Observe all ESD safety precautions before attempting this procedure. Failure to
follow ESD safety precautions might result in damage to the server.
NOTE: A hot-swappable device does not require interaction with the operating system before
the device is removed from or installed into the server.
To remove a server fan unit, follow these steps:
1. If rack mounted, slide the server completely out from the rack. See “Extending the Server
from the Rack” (page 142).
2. Remove the top cover. See “Removing the Top Cover” (page 143).
150 Removing and Replacing Server Components
