Table 5-22 I/O Card Events That May Light System Insight Display LEDs (continued)
NotesSourceCauseSample IPMI EventsDiagnostic
LED(s)
SFWPCIe link failed to
train
Type E0h, 7346d
CC_IODISC_LBA_LINK_TRAIN_ERR
I/O Card
SFWPCIe link is not
running at max
capable bandwidth
Type E0h, 7356d
IO_PCIE_LINK_SUBOPTIMAL
I/O Card
Table 5-23 PCI-X Rope to ACPI Paths
Logical ACPI PathPhysical Rope NumberPhysical Slot #
Acpi(HWP0002,PNP0A03,700)/Pci(1|0)12 - 151 - public PCI- X @ 266 MHz
Acpi(HWP0002,PNP0A03,600)/Pci(1|0)10 - 112 - public PCI- X @ 133 MHz
Acpi(HWP0002,PNP0A03,300)/Pci(1|0)4 - 73 - public PCI- X @ 266 MHz
Table 5-24 PCIe/PCI-X Rope to ACPI Paths
Logical ACPI PathPhysical Rope NumberPhysical Slot #
Acpi(HPQ0002,PNP0A08,700)/Pci(0|0)12 - 151 - public PCI- e @ 333 MHz
Acpi(HPQ0002,PNP0A08,300)/Pci(0|0)4 - 72 - public PCI- e @ 333 MHz
Acpi(HWP0002,PNP0A03,600)/Pci(1|0)10 - 113 - public PCI- X @ 133 MHz
Management Subsystem
iLO 2 MP LAN LED on the Rear Panel
The iLO 2 MP LAN supports two LEDs, viewable from the rear of the system:
1. iLO 2 MP LAN LED, which indicates link/activity status.
2. LAN LED, which shows the link speed. Only 10 Mb and 100 Mb speeds are currently
supported on the iLO 2 MP LAN.
Table 5-25 lists the iLO 2 MP LAN link statuses with their corresponding LED states:
Table 5-25 iLO 2 MP LAN LED States
LED StateLink Status
Flashing greenActivity
Steady greenLink with no activity
OffNo link
NOTE: For information on the LAN LED, see “System LAN LEDs” (page 135).
iLO 2 MP Status LEDs
There are four iLO 2 MP status LEDs on the rear panel of the server. They are as follows:
iLO 2 MP heartbeat
iLO 2 MP self-test
BMC heartbeat
Standby power
Table 5-26 lists the state of the iLO 2 MP status LEDs during normal operation.
Management Subsystem 133
