HP Integrity rx2660

8
Standby power LED
5
iLO 2 MP LAN heartbeat
LED
1
USB ports
2 9
Console serial port iLO 2 MP reset button
6
iLO 2 MP LAN self-test
LED
3 10
iLO 2 MP LAN link speed
LED
UID button/LED
7
BMC heartbeat
4
iLO 2 MP LAN link status
LED
iLO 2 MP Reset Button
The iLO 2 MP reset button enables you to reset the iLO 2 MP, and optionally reset the user-specific
values to factory default values. A momentary press causes a soft reset of the iLO 2 MP when
the button is released. A greater than four second press causes a soft reset of the iLO 2 MP upon
release; it also returns user-specific values to factory default values. The following are reset to
factory default values:
• Serial terminal baud rate settings
• User names and passwords
iLO 2 MP Ports
Table 1-4 lists a description of the iLO 2 MP ports shown in Figure 1-11.
Table 1-4 iLO 2 MP Ports
DescriptionPort
LAN port dedicated for remote access to the iLO 2 MP10 Base-T/100 Base-T LAN
Local serial portAuxiliary serial
Local serial port that provides a console connection to the serverConsole serial (iLO 2 MP)
Two public USB 2.0 ports used primarily to connect to a keyboard and mouse for
console input functions (Windows and Linux operating systems only).
USB
VGA port used primarily to connect to a monitor that displays console output
(Windows and Linux operating systems only).
VGA
iLO 2 MP LAN LEDs
Table 1-5 lists the iLO 2 MP LAN link speed LEDs and states.
Table 1-5 iLO 2 MP LAN Link Speed LEDs
LED StateLink Speed
Solid amber100 Mb
Off10 Mb
Table 1-6 lists the iLO 2 MP LAN link status LEDs and states.
Table 1-6 iLO 2 MP LAN Link Status LEDs
LED StateLink Status
Blinking greenActivity
Solid greenLink with no activity
OffNo link
iLO 2 MP Status LEDs
Table 1-7 lists the state of the iLO 2 MP status LEDs during normal operation.
Controls, Ports, and LEDs 33
