Figure 39 Fan identification
The power supplies have built-in fans and are not controlled by the iLO MP.
For fan identification, see Figure 39 (page 109).
1. Extend or remove the server from the rack (“Removing the server from the rack” (page 99) or
“Extending the server from the rack (page 95)).
2. Remove the access panel (“Removing and replacing the access panel” (page 106)).
3. Remove the fan.
CAUTION: Do not operate the server for long periods with the access panel open or
removed. Operating the server in this manner results in improper airflow and improper cooling
that can lead to thermal damage.
To replace the component, reverse the removal procedure.
Removing and replacing the power supply backplane
1. Power off the server (“Powering off the server” (page 99)).
2. Remove all power supplies (“Removing and replacing a hot-swap power supply (page 105)).
HP Confidential Removing and replacing the power supply backplane 109

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP integrity rx2800 i4 and is the answer not in the manual?

HP integrity rx2800 i4 Specifications

General IconGeneral
Number of Processors1 or 2
Memory Slots24 DIMM slots
Processor Cores4 or 8 per processor
Cache32 MB L3 per processor
MemoryUp to 384 GB DDR3
StorageUp to 8 SFF SAS/SATA drives
RAID SupportRAID 0, 1, 5, 6
NetworkIntegrated 10/100/1000Base-T Ethernet
Network ControllerHP NC382i
Expansion Slots6 PCIe 2.0 slots
Power SupplyHot-plug redundant power supplies
Operating SystemsHP-UX, Linux
Form Factor2U Rack
Processor Speed1.73 GHz, 2.13 GHz, or 2.53 GHz
