Table 37 I/O card events that might illuminate SID LEDs (continued)
NotesSourceCauseSample IPMI EventsDiagnostic
LEDs
SFWFound invalid PCIXCAP
value
Type E0h, 148d:26d
IO_UNKNOWN_PCIXCAP_VAL
I/O Card
SFWPCIXCAP sampling errorType E0h, 141d:26dI/O Card
IO_PCIXCAP_SAMPLE_ERROR
SFWExpected I/O host
bridge (Lower Bus
Adapter) is missing
Type E0h, 123d:26d
IO_CHECK_LBA_MISSING_ERR
I/O Card
SFWExpected I/O host
bridge (Lower Bus
Adapter) is deconfigured
Type E0h, 619d:26d
IO_CHECK_LBA_DECONFIG_ERR
I/O Card
SFWI/O LBA clear error
failed
Type E0h, 133d:26d
IO_LBA_CLEAR_ERR_FAILED
I/O Card
SFWI/O SBA clear error
failed
Type E0h, 144d:26d
IO_SBA_CLEAR_ERR_FAILED
I/O Card
SFWPCI-X slot power on errorType E0h, 146d:26dI/O Card
IO_SLOT_POWER_ON_ERROR
SFWPCI-X slot has incorrect
default power state
Type E0h, 145d:26d
IO_SLOT_POWER_DEFAULT_ERROR
I/O Card
SFWI/O host bridge (Lower
Bus Adapter) is
Type E0h, 136d:26d
IO_LBA_RESET_ERROR
I/O Card
inaccessible because
rope reset failed to
complete
SFWPCI clock DLL errorType E0h, 130d:26dI/O Card
IO_DLL_ERROR
SFWI/O rope reset failed to
complete
Type E0h, 143d:26d
IO_ROPE_RESET_ERROR
I/O Card
SFWPCIe link failed to trainType E0h, 7346dI/O Card
CC_IODISC_LBA_LINK_TRAIN_ERR
SFWPCIe link is not running
at max capable
bandwidth
Type E0h, 7356d
IO_PCIE_LINK_SUBOPTIMAL
I/O Card
Verifying SAS hard drive operation
Each SAS disk drive has an activity LED indicator on the front of the drive.
NOTE: On the server, only the activity LED is used. The status LED is not monitored by the OS.
Verify that the LED shows the correct activity indication for all disk drives that you installed:
1. Turn on power to the server and display monitor.
2. During the boot sequence, watch the activity LED on each SAS disk drive.
The LED quickly cycles from amber to green. The LED stays steady green until the drive spins
up.
HP Confidential Troubleshooting the I/O subsystem 87
