2 Site preparation
For information on general computer room site preparation, see the HP Generalized Site Preparation
Guide on the HP website:
http://www.hp.com/go/Integrity_Servers-docs
IMPORTANT: To avoid hardware damage, allow the thermal mass of the product to equalize to
the temperature and humidity of the installation facility after removing the shipping materials. A
minimum of one hour per 10° C (50° F) of temperature difference between the shipping facility
and installation facility is required.
Server dimensions and weight
Table 3 Rack or pedestal-mounted server dimensions
ValueDimensions and weight
Data center server dimensions
69.2 cm (27.25 in)Depth
48.3 cm (19 in)Width
8.9 cm (3.5 in)Height
Maximum configuration – 30 kg (66 lb)Weight
2URack unit
Grounding
The site building must provide a safety ground/protective earth for each AC service entrance to
all cabinets.
Install a PE conductor that is identical in size, insulation material, and thickness to the branch-circuit
supply conductors. The PE conductor must be green with yellow stripes. The earthing conductor is
to be connected from the unit to the building installation earth or, if supplied by a separately
derived system, at the supply transformer or motor-generator set grounding point.
Server electrical specifications
System power specifications
Available power (output) is the maximum DC power that the power supply can supply to the system.
Maximum input power is what the power supply requires from the AC line to deliver that maximum
DC output (given worst case efficiency and maximum loading).
Maximum input current is the worst case/highest current given the lowest input voltage and the
maximum input power.
Table 4 System power specifications
Parameter
200 - 240 V AC110 - 120 V AC100 V ACInput voltage
6.6 A9.5 A9.3 AInput current (maximum)
57 to 63 Hz47 to 53 Hz47 to 63 HzInput frequency
1200 W (MAX)
+12V /100A MAX
900 W (MAX)
+12V /75A MAX
800 W (MAX)
+12V /66.7A MAX
Power supply maximum output power
HP Confidential14 Site preparation
