1 Overview
Table 2 Hardware specifications for the server
ServerComponent
One or two Itanium quad-core or eight-core processors:Processors
• 2.53 / 2.67 GHz eight-core 32-MB cache (170W)
• 2.13 / 2.40 GHz eight-core 24-MB cache (170W)
• 2.40 / 2.67 GHz quad-core 32-MB cache (170W)
• 1.73 / 2.40 GHz quad-core 20-MB cache (130W)
Supports up to 24 Double Data Rate 3 (DDR3) DIMMs mounted on memory risers that attach
to the system board.
Memory
IMPORTANT: DIMMs must be rated for 1.35 volts.
Supported DIMM sizes are as follows:
• 4 GB
• 8 GB
• 16 GB
Minimum memory configuration is 8 GB (2 x 4 GB DIMMs) with a single CPU.
Maximum memory configuration 384 GB (24 x 16 GB DIMMs).
One to eight hot-plug SAS hard drivesDisk drives
I/O riser options:PCI slots
• One full height full length PCIe x8 and two low profile PCIe x4 slots
• One full height full length PCIe x8 and one low profile PCIe x8 slots
Eight port SAS core I/O card or eight port SAS core I/O card with internal RAIDSAS I/O
Four GigE LAN portsLAN I/O
One serial port, four USB 2.0 ports, one 1G/100/10 LAN port, and two VGA ports
NOTE: The serial port is intended primarily for use as a serial console port. It can be
configured through iLO 3 for use with other serial devices (subject to OS and device limitations
and dependencies).
Management I/O
One SATA DVD+RW driveOptical drive
One power supply which supports dual range operation (Low-line 100-120 & High-line
200-240). At low-line only 800 watts are available.
IMPORTANT: The 800 W redundancy does not apply to all configurations.
Power supply
HP Confidential8 Overview
