123
Device Interface IP
address
Device
Interface
IP address
Router A
GigabitEthernet
2/1/2
10.110.1.1/24 Router D
GigabitEthernet
2/1/2
10.110.7.1/24
Router B
GigabitEthernet
2/1/1
192.168.2.1/24 Router D
GigabitEthernet
2/1/3
10.110.8.1/24
Router B
GigabitEthernet
2/1/2
10.110.1.2/24 Router E
GigabitEthernet
2/1/1
192.168.4.1/24
Router B
GigabitEthernet
2/1/3
10.110.2.1/24 Router E
GigabitEthernet
2/1/2
10.110.4.2/24
Router B
GigabitEthernet
2/1/4
10.110.3.1/24 Router E
GigabitEthernet
2/1/3
10.110.7.2/24
Router C
GigabitEthernet
2/1/1
192.168.3.1/24 Router F
GigabitEthernet
2/1/1
10.110.9.1/24
Router C
GigabitEthernet
2/1/2
10.110.4.1/24 Router F
GigabitEthernet
2/1/2
10.110.8.2/24
Router C
GigabitEthernet
2/1/3
10.110.5.1/24 Router F
GigabitEthernet
2/1/3
10.110.3.2/24
Router C
GigabitEthernet
2/1/4
10.110.2.2/24 Router G
GigabitEthernet
2/1/1
192.168.5.1/24
Router C
GigabitEthernet
2/1/5
10.110.6.1/24 Router G
GigabitEthernet
2/1/2
10.110.9.2/24
Router H
GigabitEthernet
2/1/1
10.110.5.2/24 Source 1
—
192.168.2.10/2
4
Router H
GigabitEthernet
2/1/2
10.110.7.1/24 Source 2
—
192.168.3.10/2
4
Router I
GigabitEthernet
2/1/1
192.168.6.1/24 Source 3
—
192.168.5.10/2
4
Router I
GigabitEthernet
2/1/2
10.110.10.2/24
Configuration procedure
1. Assign an IP address and subnet mask to each interface according to Figure 45. (Details not
shown.)
2. Configure OSPF on all routers on the PIM-SM network to make sure the following conditions are
met: (Details not shown.)
{ The routers are interoperable at the network layer.
{ The routers can dynamically update their routing information.
3. Enable IP multicast routing, IGMP, and PIM-SM:
# On Router A, enable IP multicast routing.
<RouterA> system-view
[RouterA] multicast routing
[RouterA-mrib] quit
# Enable IGMP on GigabitEthernet 2/1/1 (the interface that connects to the receiver host).
[RouterA] interface gigabitethernet 2/1/1
