You can configure parameters for IGMP queries and responses for the current VLAN in VLAN view or
globally for all VLANs in IGMP-snooping view. If the configurations are made in both VLAN view and
IGMP-snooping view, the configuration made in VLAN view takes priority.
Configuring the global parameters for IGMP queries and responses
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter IGMP-snooping view.
igmp-snooping N/A
3. Set the maximum response
time for IGMP general queries.
max-response-time interval
The default setting is 10
seconds.
4. Set the IGMP last member
query interval.
last-member-query-interval interval
The default setting is 1
second.
Configuring the parameters for IGMP queries and responses in a VLAN
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter VLAN view.
vlan vlan-id N/A
3. Set the interval for sending
IGMP general queries.
igmp-snooping query-interval interval
The default setting is 125
seconds.
4. Set the maximum response
time for IGMP general queries.
igmp-snooping max-response-time interval
The default setting is 10
seconds.
5. Set the IGMP last member
query interval.
igmp-snooping
last-member-query-interval interval
The default setting is 1
second.
Configuring parameters for IGMP messages
This section describes how to configure parameters for IGMP messages.
Configuration prerequisites
Before you configure parameters for IGMP messages, complete the following tasks:
• Enable IGMP snooping for the VLAN.
• Determine the source IP address of IGMP general queries.
• Determine the source IP address of IGMP group-specific queries.
• Determine the source IP address of IGMP reports.
• Determine the source IP address of IGMP leave messages.
• Determine the 802.1p precedence of IGMP messages
Configuring source IP addresses for IGMP messages
After a Layer 2 device receives an IGMP query whose source IP address is 0.0.0.0 on a port, it does not
enlist that port as a dynamic router port. This might prevent multicast forwarding entries from being
correctly created at the data link layer and eventually cause multicast traffic forwarding failures.
