HP MSR2003 User Manual

266
Ste
p
Command Remarks
3. Enable the load splitting
function on the MLD proxy.
proxy multipath
By default, the load splitting
function is disabled.
Displaying and maintaining MLD
CAUTION:
The reset mld group command might cause IPv6 multicast data transmission failures.
Execute display commands in any view and reset commands in user view.
Task Command Remarks
Display MLD group information.
display mld [ vpn-instance
vpn-instance-name ] group
[ ipv6-group-address | interface
interface-type interface-number ] [ static |
verbose ]
N/A
Display MLD information.
display mld [ vpn-instance
vpn-instance-name ] interface
[ interface-type interface-number ]
[ proxy ] [ verbose ]
N/A
Display IPv6 multicast group
membership information
maintained by the MLD proxy.
display mld [ vpn-instance
vpn-instance-name ] proxy group
[ ipv6-group-address | interface
interface-type interface-number ]
[ verbose ]
N/A
Display information about the MLD
proxy routing table.
display mld [ vpn-instance
vpn-instance-name ] proxy routing-table
[ ipv6-source-address [ prefix-length ] |
ipv6-group-address [ prefix-length ] ] *
[ verbose ]
N/A
Display MLD SSM mappings.
display mld [ vpn-instance
vpn-instance-name ] ssm-mapping
ipv6-group-address
N/A
Clear all the dynamic group entries
of the specified MLD group or all
MLD groups.
reset mld [ vpn-instance
vpn-instance-name ] group { all | interface
interface-type interface-number { all |
ipv6-group-address [ prefix-length ]
[ ipv6-source-address [ prefix-length ] ] } }
This command cannot
remove static MLD group
entries.
MLD configuration examples
Basic MLD functions configuration examples
Network requirements
As shown in Figure 80:
