Device Interface IP address Device Interface IP address
PE 1
GigabitEthernet
2/1/3
10.110.2.1/24 CE a3
GigabitEthernet
2/1/2
10.110.5.2/24
PE 1 Loopback 1 1.1.1.1/32 CE a3
GigabitEthernet
2/1/3
10.110.12.2/24
PE 2
GigabitEthernet
2/1/1
192.168.7.1/24 CE b1
GigabitEthernet
2/1/1
10.110.8.1/24
PE 2
GigabitEthernet
2/1/2
10.110.3.1/24 CE b1
GigabitEthernet
2/1/2
10.110.3.2/24
PE 2
GigabitEthernet
2/1/3
10.110.4.1/24 CE b2
GigabitEthernet
2/1/1
10.110.11.1/24
PE 2 Loopback 1 1.1.1.2/32 CE b2
GigabitEthernet
2/1/2
10.110.6.2/24
Configuration procedure
1. Configure PE 1:
# Configure a Router ID globally, and enable IP multicast routing on the public network.
<PE1> system-view
[PE1] router id 1.1.1.1
[PE1] multicast routing
[PE1-mrib] quit
# Configure an MPLS LSR ID, and enable the LDP capability.
[PE1] mpls lsr-id 1.1.1.1
[PE1] mpls ldp
[PE1-ldp] quit
# Create VPN instance a and configure an RD and route target attributes for the instance.
[PE1] ip vpn-instance a
[PE1-vpn-instance-a] route-distinguisher 100:1
[PE1-vpn-instance-a] vpn-target 100:1 export-extcommunity
[PE1-vpn-instance-a] vpn-target 100:1 import-extcommunity
[PE1-vpn-instance-a] quit
# Enable IP multicast routing in VPN instance a.
[PE1] multicast routing vpn-instance a
[PE1-mrib-a] quit
# Create the MD for VPN instance a, and specify the default-group, MD source interface, and
data-group address range for the MD.
[PE1] multicast-domain vpn-instance a
[PE1-md-a] default-group 239.1.1.1
[PE1-md-a] source loopback 1
[PE1-md-a] data-group 225.2.2.0 28
[PE1-md-a] quit
# Assign an IP address to the public network interface GigabitEthernet 2/1/1, and enable
PIM-SM, MPLS capability, and LDP capability on the interface.
[PE1] interface gigabitethernet 2/1/1
[PE1-GigabitEthernet2/1/1] ip address 192.168.6.1 24
