HP PageWide XL 4000 User Manual

Important notes
●
Your printer must be connected to the Internet; see Congure your connectivity on page 17.
●
To congure automatic rmware updates, you can use the front panel or the Embedded Web Server; see
Congure your connectivity on page 17.
●
A rmware update package can be large; you may want to consider whether there are any implications
for your network or Internet connection.
●
A rmware update is downloaded in the background: the printer can be printing at the same time.
However, it cannot be installed in the background: printing must stop.
Manual rmware updates
Manual rmware updates can be performed in the following ways:
●
Using the Embedded Web Server, select the Setup tab and then Firmware update. Press Browse to
select a rmware le (.fmw) that you have already downloaded to your own computer.
●
Using the HP Designjet Utility under Windows, select the Admin tab and then Firmware Update.
●
Using the HP Utility under Mac OS X, select Firmware Update.
●
Using HP Web Jetadmin, with which you can make manual rmware updates or request automatic
updates.
●
Using a USB ash drive. Download the rmware le from http://www.hp.com/go/pagewidexlseries/
support/rmware/ (according to your printer model) into the USB ash drive and insert it into the Hi-
Speed USB host port in the front panel. A rmware update assistant will appear on the front panel to
guide you through the update process.
Secure File Erase
The printer's hard disk is used as a temporary storage area for print jobs. Secure File Erase can erase your
temporary les from the hard disk to protect them from unauthorized access. It begins to do so as soon as
you turn it on, but old temporary les that were already on the hard disk are not erased retroactively. If you
want to erase the old les too, see Disk Wipe on page 114.
Secure File Erase provides three dierent levels of security:
●
Non-Secure: all pointers to the information are erased. The information itself remains on the hard disk
until the disk space it occupies is needed for other purposes, and it is then overwritten. While it remains
on the disk, it is diicult for most people to access, but may be accessed using software designed for the
ENWW Secure File Erase 113

HP PageWide XL 4000 Specifications

General

Display	LED
Control type	Touch
Product color	Black, Grey
Storage media	HDD
Built-in processor	Yes
Internal storage capacity	500 GB
Sound power level (standby)	5.2 dB
Sound pressure level (printing)	53 dB
Print technology	Inkjet
Maximum resolution	1200 x 1200 DPI
Number of print cartridges	4
Page description languages	HP-GL/2, PostScript 3
Print speed (normal quality, A1)	480 pph
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Media thickness	0.4 mm
Maximum print size	-
Maximum roll width	910 mm
Maximum roll length	200 m
Maximum roll diameter	177 mm
Paper tray media types	Bond paper, Matte paper, Recycled paper
Package depth	1068 mm
Package width	2180 mm
Package height	1764 mm
Package weight	546000 g
Power consumption (typical)	400 W
Scan to	E-mail
USB connector	USB Type-A
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	864 mm
Width	1960 mm
Height	1303 mm
