Page #77 background imageLoading...
Page #77 background image
Troubleshooting
IO Conguration page
The IO Conguration page provides comprehensive print server status. It is an important diagnostic tool,
especially if network communications are not available. For a description of messages that may appear on the
IO Conguration page, see the HP Jetdirect Print Servers Administrator’s Guide for your print server model.
To print the IO Conguration page, go to the front panel and press , then Connectivity > Print
Connectivity Conguration.
To verify correct operation:
1. Print an IO Conguration page to check for status messages.
2. In the upper section of the IO Conguration page, look for the status message I/O Card Ready.
3. If I/O Card Ready appears, the print server is operating properly. Proceed to the next section.
If a message other than I/O Card Ready appears, try the following:
a. Turn the printer o and then on again to re-initialize the print server.
b. Check that the status indicator lights (LEDs) are providing proper status.
See the HP Jetdirect Print Servers Administrator’s Guide for your print server model to interpret and
troubleshoot other messages.
Reset network parameters
If you accidentally miscongured the printer’s network settings, they can be reset to factory default values by
pressing , then , then , then Restore factory settings.
CAUTION: A factory-installed HP Jetdirect X.509 certicate will be saved during reset to factory default
values. However, a Certicate Authority (CA) certicate that has been installed by the user to validate a
network authentication server will not be saved.
Link troubleshooting
The printer has status lights (LEDs) beside the network connector that indicate the link status and network
activity.
When the green light is on, the printer has successfully linked to the network.
When the yellow light is blinking, there is network transmission activity.
If the printer does not successfully connect to the network:
Both LEDs will be o.
LAN Error – Loss of Carrier will be indicated on the IO Conguration page.
In this situation, try the following:
1. Check the cable connections at both ends.
2. Consider replacing the cables by known good ones.
ENWW Troubleshooting 71

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP PageWide XL 4000 and is the answer not in the manual?

HP PageWide XL 4000 Specifications

General IconGeneral
DisplayLED
Control typeTouch
Product colorBlack, Grey
Storage mediaHDD
Built-in processorYes
Internal storage capacity500 GB
Sound power level (standby)5.2 dB
Sound pressure level (printing)53 dB
Print technologyInkjet
Maximum resolution1200 x 1200 DPI
Number of print cartridges4
Page description languagesHP-GL/2, PostScript 3
Print speed (normal quality, A1)480 pph
Sustainability certificatesENERGY STAR
Operating temperature (T-T)5 - 40 °C
Operating relative humidity (H-H)20 - 80 %
Media thickness0.4 mm
Maximum print size-
Maximum roll width910 mm
Maximum roll length200 m
Maximum roll diameter177 mm
Paper tray media typesBond paper, Matte paper, Recycled paper
Package depth1068 mm
Package width2180 mm
Package height1764 mm
Package weight546000 g
Power consumption (typical)400 W
Scan toE-mail
USB connectorUSB Type-A
USB 2.0 ports quantity1
Weight and Dimensions IconWeight and Dimensions
Depth864 mm
Width1960 mm
Height1303 mm
