HT FULLTEST3 - Page 21

FULLTEST3
EN - 19
RPE-4WIRE
- LIMIT value (STANDARD limit mode) = 0.300 :
- MODE o MANUAL
- LIMIT value 1 (STANDARD limit mode) = 0.300 :
- LIMIT value 2 (STANDARD limit mode) = 1.000 :
- LIMIT value 3 (STANDARD limit mode) = 5.00 :
- LIMIT value 4 (STANDARD limit mode) = 10.00 :
- LENGTH = 2 m
- LENGTH 1 = 2 m
- LENGTH 2 = 3 m
- LENGTH 3 = 10 m
- LENGTH 4 = 100 m
- SECTION = 1 mm
2
- SECTION 1 = 1 mm
2
- SECTION 2 = 2.5 mm
2
- SECTION 3 = 10 mm
2
- SECTION 4 = 35 mm
2
- MAT. = Cu
- Z LINE = 0.100 :
- Z
LINE 1 = 0.100 :
- Z
LINE 2 = 0.300 :
- Z
LINE 3 = 0.500 :
- Z
LINE 4 = 1.000 :
- PROTECTION = MCB B
- I
N (any protection) = 6 A
- I
N (any protection) 1 = 6 A
- I
N (any protection) 2 = 16 A
- I
N (any protection) 3 = 25 A
- I
N (any protection) 4 = 32 A
- TIMER = 3 s
- TIMER 1 = 3 s
- TIMER 2 = 10 s
- TIMER 3 = 30 min
- TIMER 4 = 60 min
RISO - MODE = MANUAL
- Um
NOM = 500 V
- LIMIT value = 0.25 M:
- TIMER = 5 s
- TIMER 1 = 5 s
- TIMER 2 = 10 s
- TIMER 3 = 1 min
- TIMER 4 = 10 min
- LIMIT value 1 = 0.25 M:
- LIMIT value 2 = 0.30 M:
- LIMIT value 3 = 1.00 M:
- LIMIT value 4 = 2.00 M:
