FULLTEST3
EN - 20
DIELECTRIC - MODE = MANUAL
- U
TEST NOM = 250 V
- LIMIT value = 1 mA
- CHAR = I
APP
- U
TEST NOM 1 = 250 V
- U
TEST NOM 2 = 1000 V
- U
TEST NOM 3 = 2500 V
- U
TEST NOM 4 = 3500 V
- RAMP TIMER = 10 s
- RAMP TIMER 1 = 10 s
- RAMP TIMER 2 = 30 s
- RAMP TIMER 3 = 1 min
- RAMP TIMER 4 = 10 min
- LIMIT value 1 = 1 mA
- LIMIT value 2 = 10 mA
- LIMIT value 3 = 50 m:
- LIMIT value 4 = 100 mA
RCD - TYPE = AC GEN
- I
'N = 30 mA
- MEAS = t/I
'N
- POL = POS
- DELAY = 100 ms
- DELAY 1 = 100 ms
- DELAY 2 = 200 ms
- DELAY 3 = 300 ms
- DELAY 4 = 700 ms
LOOP - MODE = LOOP L/N
- LIMIT mode = STD
- Ib = 1 kA
- Ib 1 = 1 kA
- Ib 2 = 3 kA
- Ib 3 = 6 kA
- Ib 4 = 25 kA
- PROTECTION = MCB B
- I
N (any protection) = 6 A
- I
N (any protection) 1 = 6 A
- I
N (any protection) 2 = 16 A
- I
N (any protection) 3 = 25 A
- I
N (any protection) 4 = 32 A
- MAT. = Cu
- COATING = PVC
- SECTION = 1 mm
2
- SECTION 1 = 1 mm
2
- SECTION 2 = 2.5 mm
2
- SECTION 3 = 10 mm
2
- SECTION 4 = 35 mm
2
- N = 1
- N 1 = 1
- N 2 = 10
- N 3 = 50
- N 4 = 75
- T
SET = 0.2 s
RA - Nominal differential current I'N = 30 mA
URES - CONNECTION = PLUG
- MODE = LINEAR
- LIMIT t = 5 s
