HT FULLTEST3 - Page 96

FULLTEST3
EN - 94
TRMS CLAMP CURRENT WITH TRANSDUCER CLAMP HT96U (ICLAMP)
Range Display range Resolution Accuracy (*)
Overload
protection
1000mA
0.0 y 99.9mA
0.1mA
±(3%rdg + 3dgt)
One measurement
terminal grounded
100 y 1000mA
1mA
100.0A
0.00 y 9.99A
0.01A
10.0 y 100.0A
0.1A
1000A
0.0 y 99.9A
0.1A
100 y 1000A
1A
(*) Accuracy of only instrument without clamp
Input voltage range: 0V y 1VAC
Input resistance: 1M:
Frequency range: 40Hz y 723 Hz (characteristics according to IEC 61557-13)
Clamp type: HT96U (measuring ranges 1 A, 100A, 1000A)
LIM value (1000mA range): Adjustable 0.1 ÷ 99.9mA, 100 ÷1000mA
LIM value (100.0A range): Adjustable 0.1 ÷ 100.0A
LIM value (1000A range): Adjustable 1 ÷1000A
TRMS LEAKAGE CURRENT WITH TRANSDUCER CLAMP HT96U (ILEAK)
Range Display range Resolution Accuracy (*)
Overload
protection
1000mA
0.0 y 99.9mA
0.1mA
±(3%rdg + 3dgt)
One measurement
terminal grounded
100 y 1000mA
1mA
100.0A
0.00 y 9.99A
0.01A
10.0 y 100.0A
0.1A
1000A
0.0 y 99.9A
0.1A
100 y 1000A
1A
(*) Accuracy of only instrument without clamp
Input voltage range: 0V y 1VAC
Input resistance: 1M:
Frequency range: 40Hz y 723 Hz (characteristics according to IEC 61557-13)
Clamp type: HT96U (measuring ranges 1 A, 100A, 1000A)
LIM value (1000mA range): Adjustable 0.1 ÷ 99.9mA, 100 ÷1000mA
LIM value (100.0A range): Adjustable 0.1 ÷ 100.0A
LIM value (1000A range): Adjustable 1 ÷1000A
TRMS LEAKAGE CURRENT ON TEST SOCKET (ILEAK)
Range Resolution Accuracy
Overload
protection
0.25 y 49.99mA
0.01 mA
± (3% rdg. + 3 dgt) CAT II 300 V
0.05 y 0.99A
0.01 A
1.0 y 10.0A
0.1 A
Load current influence ± 0.01 mA/A
Limit value: 0.25mA y 10.00A (standard limit value 3.50mA)
Frequency range 40Hz y 723Hz (characteristics according to IEC 61557-13)
Measurement method Differential current
Mains cord polarity exchange yes
UUT mains on switch test yes (limit value 25mA)
Over-range limit (IPE) yes (measurement interrupted after 10s after exceeding 10A)
Over-range limit (IL) yes (measurement interrupted after 10s after exceeding 16A
