HT FULLTEST3 - Page 95

FULLTEST3
EN - 93
FUNCTIONAL TEST – TRMS LOAD CURRENT ON SOCKET
Range [A] Resolution [A] Accuracy
Overload
protection
0.00 y 0.99
0.01
± (3%rdg. + 3dgt) CAT II 300 V
1.0 y 20.0
0.1
Frequency range: 15Hz y 723Hz
Protection: automatic interruption 10s after exceeding 16A
Pre-Test Grounding of PE terminal on schuko socket
FUNCTIONAL TEST – TRMS MAINS VOLTAGE ON SOCKET
Range [V] Resolution [V] Accuracy
Overload
protection
195 y 253
1 ± (2%rdg + 2dgt) CAT II 300 V
Frequency range 15Hz y 723Hz
FUNCTIONAL TEST – APPARENT POWER / ACTIVE POWER ON SOCKET
Range [VA/W]
Resolution
[VA/W]
Accuracy
Overload
protection
0.0 y 99.9
0.1 ±(5%rdg. + 10dgt)
CAT II 300 V
100 y 999
1
± (5%rdg. + 3dgt)
1.00 y 5.06 k
10
Limit value PAPP Adjustable 6 y 999VA, 1.00kVA y 5.06kVA
FUNCTIONAL TEST – POWER FACTOR ON SOCKET
Range Resolution Accuracy
Overload
protection
0.00 y 1.00
0.01 Depend on P
APP and PACT CAT II 300 V
FUNCTIONAL TEST – TRMS LEAKAGE CURRENT ON SOCKET
Range Resolution Accuracy
Overload
protection
0.25 y 19.99mA
0.01mA
± (3%rdg. + 3dgt) CAT II 300 V
20.0 y 49.9mA
0.1mA
0.05 y 0.99A
0.01A
1.0 y 10.0A
0.1A
Load current influence ± 0.01 mA/A
Limit value: 0.25mA y 10.00A (standard limit value 3.50mA)
Frequency range 40Hz y 723Hz (characteristics according to IEC 61557-13)
Measurement method Differential current
Mains cord polarity exchange yes
UUT mains on switch test yes (limit value 25mA)
Over-range limit (IPE) yes (measurement interrupted after 10s after exceeding 10A)
Over-range limit (IL) yes (measurement interrupted after 10s after exceeding 16A
PHASE SEQUENCE (PHASESEQ)
Range [V] Resolution [V] Accuracy
Overload
protection
360 y 460
1 ±(2%rdg + 2dgt) CAT III 300 V
Display of test result: 1.2.3 (correct) or 2.1.3 (incorrect) or 1.1.X (not defined)
