Huawei IPC6221-VRZ-SP - Page 20

Figure 3-3 GB/T 28181
Step 3 Set parameters. For detailed parameter description, see Table 3-3.
Table 3-3 GB/T 28181 parameter description
Parameter
Description
Platform IP IP address of the video surveillance
platform server.
Port number Port number of the video surveillance
platform server.
Device ID Unique IPC ID.
NOTICE
The value of this parameter must be the same as
the device ID (the code of the IVS platform, the
parameter name is Code) configured on the video
surveillance platform. If they are different, the
IPC will fail to connect to the video surveillance
platform.
Server code GB/T 28181 server code.
User-defined the value consists of 20 digits.
IPC6221-VRZ-SP
Configuration Guide
3 Setting Basic Parameters
Issue 02 (2016-04-06) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
14
