2. Use a 13# socket wrench (or solid wrench) to remove the two M8 screws and
pull out the compressor and bracket.
Do not move the compressor by moving its suction and discharge vents.
3. Remove the four nut washers and spring washers that secure the compressor
and bracket using a 13# socket wrench (or solid wrench), and remove the
compressor.
Figure 11-21 Removing the compressor bracket
Step 8 Secure the new compressor to the bracket again using a solid wrench.
NetCol5000-A050 In-row Air Cooled Smart Cooling
Product
User Manual 11 Parts Replacement
Issue 08 (2021-09-17) Copyright © Huawei Technologies Co., Ltd. 266
