Huawei Quidway S3100 Series User Manual

Operation Manual – ACL
Quidway S3100 Series Ethernet Switches Chapter 1
ACL Configuration
Huawei Technologies Proprietary
1-6
Parameter Type Function Description
source
{ sour-addr
sour-wildcard |
any }
Source
address
information
Specifies the
source address
information for
the ACL rule.
sour-addr sour-wildcard
specifies the source
address, in dotted decimal
notation.
The any keyword represents
for any source address.
destination
{ dest-addr
dest-wildcard |
any }
Destination
address
information
Specifies the
destination
address
information for
the ACL rule.
dest-addr dest-wildcard
specifies the destination
address, in dotted decimal
notation.
The any keyword represents
for any source address.
precedence
precedence
Packet
priority
IP priority
The precedence argument
ranges from 0 to 7.
tos tos
Packet
priority
ToS priority
The tos argument ranges
from 0 to 15.
dscp dscp
Packet
priority
DSCP priority
The dscp argument ranges
from 0 to 63.
fragment
Fragment
information
Specifies that
the ACL rule
applies to the
packets that are
not the first
fragments only.
—
time-range
time-name
Time range
information
Specifies a time
range for the
ACL rule to
take effect.
—
If you specify TCP or UDP as the protocol type, you can also specify the parameters
listed in
Table 1-6.
