Operation Manual – System Maintenance and Debugging
Quidway S3100 Series Ethernet Switches Chapter 1
BootROM and Host Software Loading
Huawei Technologies Proprietary
1-6
Step 5: Click the <Disconnect> button to disconnect the HyperTerminal from the switch
and then click the <Connect> button to reconnect the HyperTerminal to the switch.
Figure 1-3 Connect and disconnect buttons
 Note:
The new baud rate takes effect only after you disconnect and reconnect the terminal
emulation program.
Step 6: Press <Enter> to start downloading the program. The system displays the
following information:
Now please start transfer file with XMODEM protocol.
If you want to exit, Press <Ctrl+X>.
Loading ...CCCCCCCCCC
Step 7: Choose [Transfer/Send File] in the HyperTerminal’s window, and in the
following pop-up dialog box click <Browse>, select the software you need to download,
and set the protocol to XMODEM.
Figure 1-4 Send file dialog box
Step 8: Click <Send>. The system displays the following page.
