Quidway S3100 Series Ethernet Switches Chapter 4 Logging in Using Modem
Huawei Technologies Proprietary
4-4
Mode m
Telephone line
Mode
S
m
erial cable
Telephone number:
Console port
82882285
PS TN
PC
Mode m
Telephone line
Mode
S
m
erial cable
Telephone number:
Console port
PC
s
82882285
PS TN
Figure 4-1 Establish the connection by using modem
Step 4: Launch a terminal emulation utility on the PC and set the telephone number to
call the modem directly connected to the switch, as shown in
Figure 4-2 and Figure 4-3.
Note that you need to set the telephone number to that of the modem directly
connected to the switch.
Figure 4-2 Set the telephone number
