S1700 Managed Series Ethernet Switches
Web User Manual
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 7-2 QoS Interface configuration
Step 3 Configure the needed parameter.
Step 4 Click “Apply” button to apply all the changes made.
----End
7.2 CoS Mapping
Click QoS> Cos Mapping to configure the mapping relationship of CoS and service level; the
configuration page is shown as the figure below.
Figure 7-3 Cos Mapping
Table 7-2 Parameters of Cos Mapping
Select service level mapped by this CoS.
7.3 DSCP Mapping
Click QoS>DSCP Mapping to configure the mapping relationship between DSCP and service
level; the configuration page is shown as the figure below.
